- Greater yield, low energy consumption
- High yield, less waste, Great filling accuracy
- Easy installation, use & maintenance
Beer Cans Carton Packing Machine suitable for packing all kinds of cans into carton box.It can pack products into carton box and seal the box automatically. It also can connect with other machine,like filling machine,shrink packing machine to be a whole automatic packing line.
Model | HEM-CP |
Power supply | 3P AC380V+10% 50Hz 1KW |
Air pressure | 4-8kg/cm2 |
Control voltage | 24V DC |
Protection lever | electric appliance cabinet IP54 / pushbutton IP65 / low voltage electric element IP67 |
Worktable | customer order |
Power | 3.7kw |
Air consumption | 150L/min |
Packing speed | ≤25 pcs / min |
Container pattern | 2x2, 2x3, 3x4, 4x6 etc (customer made) |
Working noise | ≤75DB |
Environmental condition | Humidity≤98%, Temperature20-40℃ |
Item | Production capacity | Filling method | Material | Dimensions |
CM-SEMI-4-1 | 100-300CPH | Isobaric filling | SUS304 | 1700*750*2200mm |
CM-4-1 | 500-700CPH | Isobaric filling | SUS304 | 1800*1200*2200mm |
CM-12-1 | 1500-2000CPH | Isobaric filling | SUS304 | 2150*1300*1900mm |
CM-20-4 | 6000CPH | Isobaric filling | SUS304 | 2200*1750*1900mm |
BM-SEMI-4-4-1 | 240-360BPH | Isobaric filling | SUS304 | 1550*550*1750mm |
BM-6-6-1 | 500-800BPH | Isobaric filling | SUS304 | 1520*1125*2350mm |
BM-16-16-6 | 2000BPH | Isobaric filling | SUS304 | 2300*1900*2500mm |
BM-40-40-10 | 8000-10000BPH | Isobaric filling | SUS304 | 4200*3000*2700mm |
